Zy9 AC250V 10A electric steam iron thermostats adjust parts kst 207 bimetal kst thermostat

Principle
Design of KST adjustable bi-metal thermostat is based on bi-metal action in the principle of expansion and contraction. KST turns on and off within prescribed temperature range. Electric appliance will cut off when bi-metal induce temperature reach enactment value; When appliance temperature lower to enactment value,it will switch on by itself.

Electrical Ratings: AC250V/10A, AC125V/16A
Temperature Setting Range: 0~250°C
Temperature Tolerance: ±5°C
Life Cycle: no less than 100,000 times
Circuit Resistance: 50m ohms maximum

Special Features
Reliable Action
No Arc
long operating life
less interference with radio waves
control temperature exactly
Can replace ceramic fixed thermostat when using a screw instead of its axis.
control temperature and shorten temperature range through detecting current.
Can be crimped a block for installation and conducting heat.
The mounting brackets have several shapes.

Application
Widely used in Electric oven, Deep fryer, Milk heater, Sandwich Machine, Thermal wave oven, Light wave stove,Electric pressure cooker,Rice cooker,Electric room heater,Baking pan,Fan heater,Electric fry-ing pan and other electric heating products temperature and temperature limiting function.

Notes:

1:Temperature may be adjustable and non -adjustable are optional .

2:Tripping -off temperature and property curve depend on the matching test of the thermostat and clients' appliances.

3:Install manner ,dimension and angle and project direction of therminal may be designed according to clients's requirements.

4:Dimension of shaft,turn angle, switch on angle may be desinged according to cliens' requirement.

5:to facility to install it by clients, a fixing piece may be riveted on it, this piece also has the function of conducting heating.

Q1 Can I order a sample?

Of course, samples will be produced according to your requirements, free of charge, but shipping costs need to be provided on your side. When you place the order,We'll return the fee.

Q2 Are you factory/manufacturer or trader?

We are direct factory who owns commercial company and production lines.Everything is flexible and there is no need to worry about extra charges by the middle man or trader.

Q3 How about the quality ?

We have been working on the production of high quality products for 12 years,Stable product quality can meet a variety of requirements.

Q4 What is the minimum order quantity?

The min is 500 pieces.

Of course, prices will decrease as the number increases.

Q5 How long will I got the sample?

It needs 3-4 days after you confirm the sample.

Q6 How will you deliver the goods after I ordered?

It depends on your destination. Usually 20-25days after order and packing files confirmed.

Q7 Can you OEM for me?

OEM is acceptable.

Q8 Price

Approximate price range, we have shown.
The specific price needs to be determined according to your product requirements

Zy9 AC250V 10A electric steam iron thermostats adjust parts kst 207 bimetal kst thermostat

Zy9 AC250V 10A electric steam iron thermostats adjust parts kst 207 bimetal kst thermostat

Zy9 AC250V 10A electric steam iron thermostats adjust parts kst 207 bimetal kst thermostat

Our Professional manufacturer engaged in the research, development, production, sale and service of KSD301 series bimetal disc thermostat .
